GHOST E-ASX Advanced 2026

Get on and experience freedom on two wheels: The GHOST E-ASX Advanced is a fully e-mountain bike with cleverly selected components and impresses with an excellent price-performance ratio. Thanks to the robust aluminum frame and the generous suspension travel of 160mm at the front and 150mm at the rear, you can master any terrain with ease. The powerful Bosch motor and 800WH battery power guarantee you impressive power and range, even on demanding tours. Whether on the road, off-road or on adventures in nature - the E-ASX Advanced offers you the performance you need!

Brake System

Brake Front Brand: Shimano
Brake Front Kind: Deore BR-M6120, 4 pistons, 203 mm
Brake Front Mount: Post Mount
Brake Front Type: Hydraulic Disc brake
Brake Rear Brand: Shimano
Brake Rear Kind: Deore BR-M6120, 4 pistons, 203 mm
Brake Rear Mount: Post Mount
Brake Rear Type: Hydraulic Disc brake
Brake Lever Brand: Shimano
Brake Lever Kind: Deore BL-M6100
Brake Rotor Brand: Shimano
Brake Rotor Kind: SM-RT64 203 mm, Centerlock

Drivetrain

Cassette Brand: Shimano
Cassette Kind: Deore CS-M6100-12, MICRO SPLINE
Cassette Teeth: 10-51T
Chain Brand: Shimano
Chain Guide Brand: MRP
Chain Guide Kind: 1x for Bosch BDU38 32-36T
Chain Kind: Deore CN-M6100 12s
Crank Arm length: 165
Crankset Brand: Miranda
Crankset Kind: CR for Bosch BDU38, DM + XLC CR-E18 Crankarms
Crankset Teeth: 34T
Crankset Type: single
Derailleur Hanger Brand: Glory Wheel
Derailleur Hanger Kind: UDH
Derailleur Rear Brand: Shimano
Derailleur Rear Kind: Deore XT RD-M8100-SGS 12s, Shadow+
Gear Brand: Shimano
Gear Type: Derailleur
Pedal Brand: XLC
Pedal Inclusive: Yes
Pedal Kind: Flat Pedal PD-M29 w/ Reflector + integrated Pins
Shifter Right Brand: Shimano
Shifter Right Kind: Deore SL-M6100-IR, Rapidfire+
Shifter Right Type: Triggershift

E-bike Components

Battery Brand: Bosch
Battery Capacity: 800 Wh
Battery Kind: InTube 800 Wh
Battery Location: Powertube
Charger Brand: Bosch
Charger Kind: Charger 4A 220-240V
Display Brand: Bosch
Display Kind: Kiox 300 + LED Remote
Motor Brand: Bosch
Motor Torque [Nm]: 85 Nm
Motor Kind: Performance Line CX
Motor Location: Center

Frame and More

Framesize: 50 cm
Framesize Convection: XL
Max loadable weight (KG): 150 kg
Front Fork Brand: FOX Factory
Front Fork Kind: 36 Float Rhythm, GRIP, E-Optimized, QR 160 mm
Front Fork Type: Suspension
Frame Kind: HIGH
Shock Brand: FOX Factory
Shock Kind: FLOAT X Performance, A, 2pos, Evol LV, 210x55mm
Type kickstand mount: KSA18
Suspension Type: Fully
Travel Front: 160 mm
Travel Rear: 150 mm

Handlebar and Saddle

Handgrip Brand: XLC
Grip Kind: MTB Grip Set VLG-1751D2
Handlebar Brand: XLC
Handlebar Diameter: 35 mm
Handlebar Kind: HB-M34, Dia. 35 mm, Rise: 20 mm, backsweep 9°
Handlebar Material: Aluminium
Handlebar Rise: 20
Handlebar Type: Riser Bar
Handlebar Width: 800 mm
Headset Brand: Acros
Headset Kind: Blocklock 120° Tapered ZS56/ZS56
Headset Type: Semi-integrated
Saddle Brand: XLC
Saddle Kind: Sport Comfort SA-S11 Steel Rail 155 mm
Seatpost Brand: XLC
Seatpost Kind: Dropper SP-T21, Dia. 34.9 mm, Travel: 200 mm
Seatpost Length: 555 mm
Seatpost Material: Aluminium
Seatpost Travel (mm): 200 mm
Seatpost Type: Dropperpost
Stem Brand: XLC
Stem Kind: ST-M50, Dia. 35 mm, L: 50 mm, A-Head
Stem Length: 50 mm

Wheels and Wheel Components

Hub Front Brand: XLC
Hub Front Kind: HF-M55 Boost 15x110 mm, 32H, Centerlock
Hub Rear Brand: XLC
Hub Rear Kind: HR-M55 Boost 12x148 mm, 32H, Centerlock, MS
Rim Brand: XLC
Rim Kind: WR-M39 Disc 30/622 32H 6,5 mm Valve
Rim Rear Brand: XLC
Rim Rear Kind: Tryp EVO Disc 30/584 32H 6,5 mm Valve
Spoke Brand: DT Swiss
Spoke Kind: FACTORY 2.0
Tyre Brand: Continental
Tyre Kind: Xynotal Trail Endurance, foldable skin SL
Tyre Rear Brand: Continental
Tyre Rear Kind: Xynotal Trail Endurance, foldable skin SL
Tyre Size Etrto: 60-622
Wheel Size Front: 29
Wheel Size Rear: 27.5
